Angle Control Valve
Concorde Valves & Automations: India's Leading Manufacturer and Supplier of Angle Control Valve
In the world of industrial fluid control, precision, reliability, and efficiency are paramount. At Concorde Valves & Automations, we are proud to be recognized as India’s leading manufacturer and supplier of high-quality angle control valves. Our valves are designed to meet the rigorous demands of various industries, ensuring optimal performance, safety, and longevity.
What is an Angle Control Valve?
An angle control valve, also known as a control angle valve, is a specialized type of valve used to regulate the flow of fluids in industrial piping systems. The distinguishing feature of an angle control valve is its unique 90-degree angle design, which allows for directional flow changes within a system. This design is particularly beneficial in applications where space is limited or where a change in flow direction is required.
Angle control valves are commonly used in industries such as oil and gas, chemical processing, water treatment, and power generation. They are highly valued for their ability to provide precise control over fluid flow, pressure, and temperature, making them an essential component in complex industrial processes.
Why Choose Concorde Valves & Automations for Angle Control Valves?
As India’s premier angle control valve manufacturer, Concorde Valves & Automations offers unmatched expertise and quality in valve production. Here’s why our products stand out:
- Expertise and Experience: With years of experience in the valve manufacturing industry, we have developed a deep understanding of control valve technology, allowing us to create products that meet the highest industry standards.
- Superior Quality: Our angle control valves are made from the finest materials, ensuring durability, reliability, and long-term performance even in the most demanding environments.
- Custom Solutions: We recognize that every industrial application is unique. That’s why we offer customized angle control valves tailored to your specific needs, ensuring optimal performance and efficiency.
- Competitive Pricing: We offer our high-quality angle control valves at competitive prices, providing excellent value for money without compromising on quality.
- Comprehensive Support: Our commitment to customer satisfaction extends beyond just supplying valves. We provide comprehensive support, from initial consultation to after-sales service, ensuring that your valves continue to operate at their best.
Specifications of Angle Control Valve
To help you understand the technical capabilities of our angle control valves, here is a detailed specifications table:
| Size Range | DN 50 to DN 1200 |
| Pressure Rating | PN 10, PN 16, PN 25, PN 40, ANSI 150-600 |
| End Connection | Flanged Ends as per ASME, DIN, BS standards |
| Standards | Conforming to IEC, ISA, ANSI, API standards |
| Seating Material | EPDM, NBR, Viton, PTFE |
| Body Material | Stainless Steel, Carbon Steel, Cast Iron, Alloy Steel |
| Trim Material | Stainless Steel, Hastelloy, PTFE, Tungsten Carbide |
| Actuator Type | Pneumatic, Electric, Hydraulic |
| Flow Characteristic | Linear, Equal Percentage, Quick Opening |
| Seat Leakage | Class IV, V, VI |
| Temperature Range | -50°C to 450°C (depending on material) |
| Control Signal | 4-20 mA, 0-10 V DC |
Applications of Angle Control Valve
Angle control valves are versatile and find applications across various industries. Here are some of the key applications:
- Oil & Gas Industry: Used for controlling the flow of crude oil, natural gas, and other hydrocarbons in pipelines, processing plants, and refineries.
- Chemical Processing: Essential for regulating the flow of aggressive chemicals, acids, and other hazardous fluids in processing units.
- Water Treatment: Critical for managing the flow of water and treatment chemicals in purification plants, desalination units, and wastewater treatment facilities.
- Power Generation: Employed in controlling steam, cooling water, and other fluids in power plants, contributing to efficient and safe power production.
- Pharmaceuticals: Ensures precise control over the flow of ingredients and solvents in the manufacturing of pharmaceutical products.
Understanding Angle Valve Types
There are several types of angle control valves available, each designed to meet specific application requirements:
- Globe Angle Valve: Features a globe-shaped body and is ideal for applications requiring throttling and precise flow control.
- Diaphragm Angle Valve: Uses a diaphragm to regulate flow, making it suitable for applications involving corrosive or viscous fluids.
- Ball Angle Valve: Incorporates a ball mechanism to control flow, known for its durability and ability to handle high-pressure applications.
- Butterfly Angle Valve: A lightweight valve with a disc mechanism, used for quick shut-off and control in large-diameter pipelines.
Angle Valve Diagram and How It Works
An angle valve diagram typically shows the flow path of the fluid through the valve body. The fluid enters through the inlet, changes direction at a 90-degree angle, and exits through the outlet. The valve’s actuator adjusts the position of the internal mechanism (such as a globe, diaphragm, or ball), controlling the flow rate and direction.
Why Concorde Valves & Automations is Your Best Choice
As the leading angle control valve manufacturer in India, Concorde Valves & Automations is dedicated to providing top-quality products that meet the evolving needs of our customers. Our commitment to innovation, quality, and customer satisfaction makes us the preferred choice for industries across the country.
