Ball Foot Valve, Screwed End — Compact Pump Priming Protection

Reliable threaded foot valves in CI, brass and SS for pump suction protection across industries.

Ball Type Foot Valve Screwed End — Manufacturer & Supplier in India

Concorde Valves & Automations is a trusted ball type foot valve screwed end supplier in India, manufacturing threaded foot valves in cast iron, brass and stainless steel for reliable pump suction line protection. Our screwed-end foot valves are precision-built under ISO 9001:2015 certified processes at our Mumbai facility and dispatched pan-India and for export.

A threaded foot valve threads directly onto the pump suction inlet, retaining water in the suction line to prevent pump priming loss. The free-floating ball seats instantly when the pump stops — blocking reverse flow without any manual action — while the integrated strainer keeps debris out of the pump casing.

Whether you need a ball type foot valve screwed end for a new installation, a replacement, or an OEM order, we offer competitive pricing, fast ex-stock dispatch from Mumbai, and technical support to help you select the right material and size for your application.

Need a specific brand? We also supply Advance Valves and other leading brands on request — mention this when you enquire and we will quote accordingly.

Request a Quote
Ball type foot valve screwed end manufactured by Concorde Valves & Automations India

Threaded Foot Valve Supplier in Mumbai and Across India

As a leading threaded foot valve supplier, Concorde Valves serves customers across Mumbai, Pune, Ahmedabad, Surat, Chennai, Hyderabad, Delhi and all major industrial hubs in India. We maintain ex-stock inventory in the most popular sizes — so you are not waiting weeks on a special order when a pump is down.

Our screwed end (threaded) foot valves are built for smaller-bore suction piping where flanged connections would be over-engineered and cost-prohibitive. BSP and NPT threading is available to match your existing pipework, with sizes from ½" to 4" covering domestic motor lines, irrigation pump sets, construction dewatering, and light industrial process pumps.

Beyond foot valves, we supply a complete range of industrial valve and automation solutions — from pneumatic diaphragm control valves to electrically operated butterfly valves — for complex industrial pipeline systems.

Call +91 9326435528
Concorde Valves — threaded foot valve supplier delivering to industries across India from Mumbai

Why Choose Concorde Valves & Automations?

Quality, certification and dependable supply that industrial buyers across India rely on.

ISO 9001:2015 Certified Manufacturing

Every valve is produced under a certified quality management system. Consistent precision and repeatable reliability in each batch.

Authorised KITZ Valves Distributor

Genuine KITZ valves supplied through authorised channels in India. Global brand quality backed by responsive local support.

Tested to Recognised Standards

All products validated against recognised international standards. Verified performance and documentation before every dispatch.

14+ Years Industry Experience

Over a decade serving water, oil, gas, chemical and HVAC sectors. Deep technical know-how across diverse applications.

Customised Solutions for Projects & OEMs

Tailored sizes, materials and specifications for your project. Flexible support for OEM, bulk and replacement orders.

Pan India Supply & Export Capability

Fast dispatch from our Mumbai facility to every industrial hub. Export-ready packaging and complete documentation.

Types of Ball Type Foot Valve Screwed End

We manufacture and supply screwed end ball type foot valves in multiple body materials — each suited to a different range of fluids, pressures and service environments. All types feature BSP or NPT threaded connections and an integrated debris strainer.

PVC / Plastic Threaded Foot Valve

Lightweight and fully corrosion-resistant. A common choice for domestic water lines, borewell pump sets and chemical applications where metal corrosion is a concern.

Cast Iron (CI) Threaded Foot Valve

Rugged and cost-effective for heavy-duty industrial pumping — irrigation mains, construction dewatering, municipal water supply and general industrial fluid transfer.

Brass Threaded Foot Valve

The standard choice for domestic water motors, smaller pump sets and general-purpose lines. Good corrosion resistance at a competitive price point.

Stainless Steel (SS) Threaded Foot Valve

Built for harsh, corrosive and hygienic environments — chemical process plants, food and beverage, pharmaceutical and marine applications.

Spring-Loaded Threaded Foot Valve

Spring-assisted closing gives a quicker, positive seal compared to a gravity-close design — preferred where there is minimal backpressure to seat the ball reliably.

Strainer-Integrated Foot Valve

All our screwed end foot valves are supplied with a built-in strainer basket to stop debris from entering the pump suction — reducing wear and preventing impeller damage.

Diagram showing how a ball type foot valve screwed end works

How a Threaded Foot Valve Works

A ball type foot valve screwed end is installed at the suction inlet of a pump — typically submerged in the water source or sump. The BSP or NPT threaded connection lets you spin it directly onto existing pipework without flanges, special tools, or welding.

When the pump starts, the suction pressure lifts the ball off its seat, allowing liquid to flow freely up the suction line and into the pump. The integrated strainer at the inlet prevents debris from entering with the flow. When the pump shuts down, the ball drops back under gravity and reverse pressure, sealing the pipe immediately and keeping the suction column primed. At the next start, the pump picks up on a full, primed line — no air locks, no dry-running damage, no wasted re-priming time.

This simple, self-acting mechanism is why the threaded foot valve remains the most common pump-protection fitting in water supply, agriculture, construction dewatering and light industrial process lines.

Applications of Ball Type Foot Valve Screwed End

Our threaded foot valves are used wherever a pump suction line must be kept primed between cycles — from domestic water motors to industrial process pumps.

Water Supply & Pumping Systems

Agricultural Irrigation Pump Sets

Industrial Fluid Transfer Lines

Chemical Processing Plants

Construction & Dewatering Applications

Borewell & Submersible Pump Installations

Benefits & Technical Specifications

Compact threaded installation, reliable prime retention and integrated strainer protection make our screwed end foot valves a cost-effective choice for smaller-bore pump suction applications.

Benefits

  • Reliable pump priming and backflow prevention — Keeps the suction line full at all times, protecting pumps from air locks and dry-running damage.
  • Simple, compact installation — BSP/NPT threads allow the valve to be fitted directly onto existing pipework without flanges, special tools or welding.
  • Choice of body materials — Cast iron, brass and stainless steel options cover water, oil, mild chemicals and corrosive media.
  • Integrated strainer protection — Built-in strainer basket stops debris from entering the pump suction at the source.
  • Fully automatic operation — Self-acting ball mechanism prevents reverse flow with no manual intervention during pump cycles.
  • Low pressure drop — Full-bore flow path ensures the pump operates at full efficiency without avoidable energy loss.
  • Low maintenance requirements — Minimal moving parts keep servicing simple and downtime low over extended service life.

Technical Specifications

Valve TypeBall Type Foot Valve
End ConnectionScrewed / Threaded End (BSP / NPT)
Size Range½" to 4" (DN15 to DN100)
Pressure RatingUp to 10 Bar (PN10)
Body MaterialCast Iron (CI) / Brass / Stainless Steel (SS 304 / SS 316)
Ball / ClosureRubber-coated steel ball / NBR coated
StrainerIntegrated (supplied as standard)
MediaWater, Oil, Mild Chemicals, General Industrial Fluids
Temperature RangeUp to 80°C
Thread StandardBSP (British Standard Pipe) / NPT (available on request)

Quality Assurance & Testing

Every ball type foot valve screwed end passes a strict multi-step inspection process before dispatch to ensure reliable non-return performance in the field.

Hydrostatic Pressure Testing

Valve body is tested to rated pressure under water to confirm zero leakage before it leaves the production line.

Seat Leakage Testing

Ball-to-seat sealing is verified across all sizes to confirm effective non-return performance in the installed position.

Dimensional Accuracy Checks

Thread pitch, bore size and face-to-face dimensions are inspected against manufacturing tolerances for correct pipeline fitment.

Performance Validation

Ball mechanism operation, strainer integrity and flow performance are tested under simulated working conditions before dispatch.

What Our Clients Say

Trusted by procurement teams, EPC contractors and plant engineers across India.

"

We have been sourcing ball type foot valves from Concorde Valves for the past two years and the quality has been consistently excellent. The screwed end connections fit perfectly without any leakage issues. Highly recommend them for industrial valve requirements.

Rajesh PatelProcurement Manager, Ahmedabad
"

Concorde Valves delivered our order on time and the valves have been performing without any issues since installation. The stainless steel foot valves we ordered for our chemical plant have shown great corrosion resistance. Very satisfied with the product quality and service.

Mihir ShahPlant Engineer, Surat
"

We needed foot valves urgently for a construction dewatering project and Concorde Valves arranged quick dispatch without compromising on quality. The valves have been running continuously for months without a single failure. Will definitely order again.

Dipak DesaiSite Manager, Vadodara

Why Buyers Trust Concorde

Every claim below can be verified before you place an order — ask us for the certificate, distributorship confirmation or registration number and we will send it.

Authorised KITZ Distributor Since 2011

KITZ product comes through authorised channels, not the grey market — with KITZ's own cast body markings, figure number and pressure rating intact.

ISO 9001:2015 Certified

Our manufacturing runs under a certified quality management system, and the same process governs how bought-in product is received, stored and despatched.

Manufacturer's Test Certificate

Ask at order stage and we supply the MTC against your batch. On KITZ product that is the manufacturer's own certificate, not a document we generate.

MSME Registered

A registered Indian manufacturer — which matters where your procurement policy requires it, and where MSME payment terms apply to the purchase.

Quote Within 24 Hours

Send size, material and end connection and you get price, availability and lead time inside a working day — or a straight answer if we cannot supply it.

We'll Say If It's the Wrong Valve

Because we both manufacture and distribute, we have no reason to push one over the other. If the material is wrong for your fluid or the class is under-rated, we say so before quoting.

Need a Quote on Ball Type Foot Valve Screwed End?

Get competitive pricing on durable CI, brass and SS threaded foot valves — ½" to 4". Fast ex-stock dispatch from Mumbai with pan-India delivery and export support. As a dedicated ball type foot valve screwed end supplier, we respond within 24 hours.

Frequently Asked Questions

Common questions about ball type foot valve screwed end — materials, sizing, pressure ratings and selection guidance.

A ball type foot valve with screwed end is a one-way valve installed at the bottom of a pump suction pipe. It uses a ball mechanism to allow flow in one direction and prevent backflow when the pump stops, with threaded (BSP/NPT) connections for easy installation on smaller-bore piping.

A threaded foot valve is installed on the suction inlet of a pump to retain water in the suction line and prevent the pump from losing its prime when it shuts down. It is widely used in water supply, agriculture, construction dewatering, and industrial fluid transfer applications.

When the pump starts, fluid pressure lifts the ball off its seat, allowing flow through the valve. When the pump stops, the ball drops back and seals the pipe, preventing water from flowing back and keeping the suction line primed and ready for the next start cycle.

A screwed end (threaded) foot valve threads directly onto smaller-bore pump suction piping for quick, economical installation without special tools. A flanged end valve uses bolted flanges and is preferred for larger-diameter pipelines where higher mechanical strength is needed.

Concorde Valves manufactures screwed end ball type foot valves in cast iron (CI), brass and stainless steel (SS 304 / SS 316). Material selection depends on the fluid handled, operating pressure and environmental conditions.

Our screwed end foot valves are available from ½ inch to 4 inch (DN15 to DN100), covering most standard pump suction and pipeline requirements. Custom sizes can be quoted on request.

Standard screwed end foot valves are pressure-rated up to 10 Bar (PN10). Higher-pressure variants are available depending on body material and application requirements — contact us to discuss your working pressure.

Yes. Ball type foot valves are widely used with borewell and submersible pumps to maintain suction line priming and prevent reverse flow after the pump shuts down.

These valves are suitable for water, oil, mild chemicals and slightly contaminated fluids. Select CI for general water and industrial service, SS for corrosive or hygienic media, and brass for domestic motor lines and general-purpose installations.

Ball type foot valves require minimal maintenance. A periodic inspection every 6 to 12 months is recommended to check for seat wear, debris in the strainer, or seal deterioration — especially in applications with suspended solids.

Yes. Our ball type foot valves are supplied with an integrated strainer to protect the pump from debris entering the suction line.

Concorde Valves & Automations is both a manufacturer and a ball type foot valve screwed end supplier in India. We also act as dealer and distributor for bulk and OEM requirements, with fast ex-stock dispatch from our Mumbai facility.
